Part# 20104122
Apache's ZipLink belt features a smooth, white nitrile cover on a polyester monofilament spiral mesh carcass. The ZipLink design eliminates mechanical lace and replaces time consuming, costly, vulcanized endless splices. Features a longer service life due to no "weak link", eliminating failures common to other splices.
The smooth nitrile cover offers good cut and abrasion resistance, as well as excellent oil resistance. Using a simple hand tool this belt can be easily spliced on-site to any length, or supplied with prepared ends for quicker installation. Troughable and easily tracked, this is an ideal belt for food and oily applications.
SPECIFICATIONS
-
UPC: 725559312663
-
Spec#: 4122
-
Ply: 1
-
Working Tension: 150
-
Color: Blue
-
Compound: Carbox Nitrile
-
Carcass: Plastic Mesh
-
Top Surface: Smooth
-
Bottom Surface: Bare
-
Thickness / Overall Gauge: 0.140"
-
Weight (PIW): 0.125
-
Elongation @ 100%: 2%
-
Minimum Pulley: 2.5"
-
Temperature Range: 0°F to 250°F
-
Oil Resistant: Yes
-
Clipper®: Not Recommended
-
Alligator ®: Not Recommended
-
Staple: Not Recommended
-
Solid Plate: Not Recommended
-
Flexco® Bolt On: Not Recommended
-
Flexco® Rivet: Not Recommended
-
Endless Splice: ZipLink Splice
